Meraki PoE Injector
Technical infomations
| Brand Name | Meraki |
| Certifications & Standards |
|
| Depth | 165.9 mm |
| Form Factor | Wall Mountable |
| Height | 42.7 mm |
| Input Ports | 1 x 10/100/1000Base-T |
| Input Voltage | 120 V AC |
| Input Voltage | 230 V AC |
| Manufacturer Part Number | MA-INJ-5-UK |
| Manufacturer Website Address | http://www.cisco.com/global/fr/ |
| Manufacturer | Cisco Systems, Inc |
| Marketing Information | Reliable, standards-compliant power for your Meraki devices Increased Flexibility, Reduced Installation Time and Cost One of the main constraints when designing your wireless network is the availability of power. Running power cabling is also a primary cost driver of wireless installations. The Meraki multigigabit PoE injector allows delivery of both data and power to a Meraki access point over a single Ethernet cable, allowing deployment of devices exactly where they are needed to provide the best wireless coverage at a much lower installation cost. The Meraki Multigigabit 802.3at PoE Injector provides fully-compliant 802.3at detection, with disconnect, short-circuit and overload protec - tion. This ensures that only 802.3at and 802.3af devices receive power and non-compliant devices are not accidentally damaged. Using this injector, it is possible to power the latest generation of 802.11ac devices that require 802.3at power delivered via multigigabit inter - faces, as well as providing backward compatibility with legacy 802.11n devices with traditional 802.3af power. Regardless of the deployment scenario, powering Meraki devices with multigigabit 802.3at Power over Ethernet is a flexible and low-cost method to simplify the installation process while ensuring that net - work design is not compromised by power availability limitations. |
| Maximum Frequency | 60 Hz |
| Maximum Input Current | 1.50 A |
| Maximum Output Power | 30 W |
| Maximum Output Voltage | 55 V DC |
| Minimum Frequency | 50 Hz |
| Output Ports | 1 x 10/100/1000Base-T |
| Product Name | Multigigabit 802.3at Power over Ethernet Injector |
| Product Type | PoE Injector |
| Weight (Approximate) | 412.8 g |
| Width | 87.9 mm |
